MXQ Disc Pumps
MXQ Disc Pumps
Features:
Disc pumps offer various advantages in hard-to-pump applications making them the future of pump technology. Some key features of these pumps are:
- Disc pumps are capable of transferring abrasive, air-entrained fluids, as well as viscous fluids and high solid slurries.
- Fluids with particulate matter, solids, and trapped air can also be transferred through these pumps.
- Unlike the other conventional pumps, these pumps have no close tolerances, offer a pulsation-free flow and operate based on a non-contact pumping action. All the mentioned features contribute to high reliability and uptime by preventing solids from clogging
- As much as these pumps can handle highly viscous fluids and solids, they can also process fragile products without any damage.
- They are sturdy and corrosion resistant; therefore, the wear and tear that occurs due to abrasive fluids is minimal. Therefore, both repairs and spare parts requirements are low.
- They have dry-run capability. They can operate without processing fluid; however, in this case, the mechanical seal needs to be flushed.
- Their discs have low radial and axial loads, which help to extend shaft, bearing, and seal life.
- The net positive suction head (NPSH) required is far lower than most other pumps.
All these features reduce the overall cost and time in the long run.
Performance:
- Flows: 5 – 4,000 GPM
- Suction Pressures: Low NPSHr
- Discharge Pressures: Up to 300 PSI
- Operating Temperatures: up to 500 F
- Viscosities: Up to 100,000 cPs
- Solid Sizes: Up to 4’’
- Pump Speeds: 3,600 RPM
- Disc Impellers: 8’’ – 20’’ (larger upon demand)
- Viscous slurries up to 100,000 cps
- Fluids with entrained air up to 35% entrained air
- High solid content up to 75-80% solids
- Abrasive fluids (i.e. mining, asphalt, etc.)
- Shear sensitive fluids (i.e. latex, polymers, blood, etc.)
XD DISC - OUR MOST PREMIUM DISC PUMP
The essence of the MXQ DiscSet is to
generate minimum impingement while
maintaining a balance between efficiency
and efficacy.
The fluid is free-flowing and gently
propelled without the constraint of vanes.
LD DISC - OUR MOST ECONOMICAL DISC DESIGN
Available in,
20HP – 150HP
1200, 1800, and 3600 RPM
Sizes 3x2x13 to 8x6x14
Max Flow: 200 PSI
Max Pressure: 2500 GPM
Max Suction Lift: 25ft
MXQ Submersible Disc
MXQ submersible disc pumps can handle fluids with high viscosity (up to 50,000 cP), high solids (up to 60%), and entrained air or gas (Up to 50% at low rpms and low flow and TDH). They also generate very little shear making them an excellent option for thixotropic or dilatant media. Self-cooling motors can also be provided allowing the motors to be kept cool for high temperature applications, or even run dry permanently.
